Appendices

Appendix A: DLLs used to support coupon projects

The DDLs used to support this functionality are listed below and should reside in the primary database and schema that RPI is configured to use. Using an Auxiliary database may also be an option, but that has not been validated or tested at this point.

Coupon pool

SQL
-- Coupon Pool Table Create Statement
CREATE TABLE [dbo].[RPI_COUPON_POOL](
	[promotion_code] [varchar](100) NOT NULL,
	[coupon_code] [varchar](100) NOT NULL,
	[display_name] [varchar](100) NOT NULL,
	[max_uses] [int],
	[start_date] [datetime],
	[expiration_date] [datetime],
	[allocated] [int],
	[allocation_ts] [datetime],
) ON [PRIMARY]
GO

Field reference

Field name

Description

promotion_code

This is the name of the promotion that the codes are associated to. This will be used to define a view to support using as the source of the metadata values.

coupon_code

This is the coupon code itself and should be unique in the table.

display_name

This would be used if you had a name that you wanted to display along with the coupon itself. Some examples are: Birthday Coupon Code or 20 Percent Off.

max_uses

This field is not a part of the sample coupon allocation project, but could be implemented if that is a requirement.

This is used to support multi-use codes and specifies what the limit of uses is.

start_date

This field is not a part of the sample coupon allocation project, but could be implemented if that is a requirement.

Start date can be used to define when a coupon is valid.

expiration_date

This field is not a part of the sample coupon allocation project, but could be implemented if that is a requirement.

Expiration Date can be used to define when a coupon is invalid.

allocated

This is field is set to true when a coupon is allocated in production.

allocation_ts

This is the timestamp of when the coupon was allocated.

Coupon assignment

Keep in mind that this example table uses names like resolution_key_int01 to support any resolution keys that are integers and used as a resolution to which coupons are getting assigned. We have a similar set for strings (resolution_key_str01). These generic names could be used or you could rename these columns to the specific names of the resolution keys, if that makes things easier to understand. You would just need to make sure that the RPDM project is updated to support the name changes.

Using multiple resolutions for assigning coupons is possible, but requires some additional configuration in RPI and RPDM.

SQL
CREATE TABLE [dbo].[RPI_COUPON_ASSIGNMENT](
      [coupon_assignment_id] [int] IDENTITY(1,1) NOT NULL,
      [promotion_code] [varchar](100) NOT NULL,
      [coupon_code] [varchar](100) NOT NULL,
      [coupon_type] [varchar](100) NOT NULL,
      [RPIResolutionKey] [varchar](100),
      [resolution_key_int01] [bigint],
      [resolution_key_int02] [bigint],
      [resolution_key_int03] [bigint],
      [resolution_key_str01] [varchar](100),
      [resolution_key_str02] [varchar](100),
      [resolution_key_str03] [varchar](100),
      [insert_ts] [varchar](100) NOT NULL,
      [dataflow_id] [varchar](100) NOT NULL,
      [workflow_id] [varchar](100) NOT NULL,
      [output_id] [varchar](100) NOT NULL
) ON [PRIMARY]
GO

Field reference

Field name

Description

coupon_assignment_id

This is an identity column that will be unique for all records in this table.

promotion_code

This is the name of the promotion that the codes are associated to. This will be used to define a view to support using as the source of the metadata values.

coupon_code

This is the coupon code itself.

coupon_type

Indicates if it is a Group or Individual coupon code.

RPIResolutionKey

This is the RPI Resolution Key field name for the audience being used with the coupon assignment process.

resolution_key_int01

This is a placeholder for an integer type resolution key. It can be left with this default name or be renamed to match the name of the resolution key that will be loaded to the field.

resolution_key_int02

Additional integer-based resolution key field if coupons need to be assigned using more than one resolution.

resolution_key_int03

Additional integer-based resolution key field if coupons need to be assigned using more than one resolution.

resolution_key_str01

This is a placeholder for a string type resolution key. It can be left with this default name or be renamed to match the name of the resolution key that will be loaded to the field.

resolution_key_str02

Additional string-based resolution key field if coupons need to be assigned using more than one resolution.

resolution_key_str03

Additional string-based resolution key field if coupons need to be assigned using more than one resolution.

dataflow_id

Dataflow ID that is in the temp table when the coupon project is executed.

workflow_id

Dataflow ID that is in the temp table when the coupon project is executed.

output_id

Dataflow ID that is in the temp table when the coupon project is executed.

Promotion code view

The promotion code view is used to support dynamically updating the list of promotion codes to be selected in RPI when setting the metadata. As new promotion codes are loaded, they will be available for selection in RPI.

Replace <RPI Primary Database Name> with the name of the primary RPI Database.

SQL
USE <RPI Primary Database Name>;

GO

SET ANSI_NULLS ON;

GO

SET QUOTED_IDENTIFIER ON;

GO

CREATE VIEW [dbo].[RPI_UNIQUE_COUPON_PROMOTION_CODE] AS
    SELECT DISTINCT Promotion_Code
    FROM <RPI Primary Database Name>.[dbo].[RPI_COUPON_POOL];

GO

Appendix B: Stored procedures used by the coupon assignment project

sp_RedPoint_ForceWaitDM

This Stored procedure forces the RPDM job to pause for a duration of time so that you can attach to the project when debugging or modifying the RPDM project and want to watch it execute.

SQL
CREATE PROCEDURE [dbo].[sp_RedPoint_ForceWaitDM]
    @outvar     int      OUTPUT,
    @retryDelay char(8)  = '00:00:00'
AS
BEGIN
    DECLARE @ReturnInfo varchar(255);

    -- Validate the @retryDelay parameter
    IF ISDATE('2000-01-01 ' + @retryDelay + '.000') = 0
    BEGIN
        SELECT @ReturnInfo = 'Invalid time ' + @retryDelay + ', hh:mm:ss, submitted.';
        PRINT @ReturnInfo;
        RETURN(1);
    END

    -- Delay execution for the specified time
    WAITFOR DELAY @retryDelay;

    -- Set output variable
    SELECT @outvar = 1;
END

sp_RPI_CouponProject_Lock

This stored procedure is used to see if it can lock the project for execution. If it fails to get a lock, it will delay and retry a configurable number of times before failing the interaction. If the project is not being run at the time this procedure is executed or after a retry, it will lock the project by updating the coupon_project_runstatus table with a status of running. At that point, the coupon project will run and assign the appropriate coupons.

SQL
CREATE PROCEDURE [dbo].[sp_RPI_CouponProject_Lock]
    @result     int      OUTPUT,
    @numRetries int,
    @retryDelay char(8)  = '00:00:00'
AS
BEGIN
    DECLARE @ReturnInfo varchar(255);

    -- Validate the @retryDelay parameter
    IF ISDATE('2000-01-01 ' + @retryDelay + '.000') = 0
    BEGIN
        SELECT @ReturnInfo = 'Invalid time ' + @retryDelay + ', hh:mm:ss, submitted.';
        PRINT @ReturnInfo;
        RETURN(1);
    END

    SET NOCOUNT ON;

    DECLARE @lockCheck int = 0;

    -- Check for idle status with lock_id = 1
    SELECT @lockCheck = COUNT(*)
    FROM coupon_project_runstatus WITH (TABLOCKX)
    WHERE lock_id = 1 AND STATUS = 'idle';

    -- If lock is available, update the status to 'running'
    IF @lockCheck = 1
    BEGIN
        UPDATE coupon_project_runstatus
        SET STATUS = 'running'
        WHERE lock_id = 1;
        SET @result = @lockCheck;
    END
    ELSE
    BEGIN
        DECLARE @retry int = 1;

        -- Retry mechanism if lock is not available
        WHILE @retry <= @numRetries
        BEGIN
            -- Wait for the specified delay
            WAITFOR DELAY @retryDelay;

            -- Increment retry counter
            SET @retry = @retry + 1;

            -- Check lock status again
            SELECT @lockCheck = COUNT(*)
            FROM coupon_project_runstatus WITH (TABLOCKX)
            WHERE lock_id = 1 AND STATUS = 'idle';

            -- If lock becomes available, update status and exit loop
            IF @lockCheck = 1
            BEGIN
                UPDATE coupon_project_runstatus
                SET STATUS = 'running'
                WHERE lock_id = 1;
                SET @result = @lockCheck;
                BREAK;
            END
        END
    END

    -- Set the final result
    SET @result = @lockCheck;

END;

GO

coupon_project_runstatus

This is the table that is used to support the locking of the project to prevent concurrent execution.

SQL
CREATE TABLE [dbo].[coupon_project_runstatus] (
    [lock_id]   [int]          NOT NULL,
        NOT NULL,
    CONSTRAINT [PK_coupon_project_runstatus] PRIMARY KEY CLUSTERED
    (
        [lock_id] ASC
    )
    WITH (
        PAD_INDEX = OFF,
        STATISTICS_NORECOMPUTE = OFF,
        IGNORE_DUP_KEY = OFF,
        ALLOW_ROW_LOCKS = ON,
        ALLOW_PAGE_LOCKS = ON
    ) ON [PRIMARY]
) ON [PRIMARY];

GO

-- Insert an initial record into the table
INSERT INTO [dbo].[coupon_project_runstatus] ([lock_id], [status])
VALUES (1, 'idle');

GO

Appendix C: RPI to RPDM integration configuration

This section provides some details on integrating RPI with RPDM.

There is more extensive documentation on setting up and using Data Process Projects that provides additional details on configuration and the additional ways that Data Process Projects can be used.

Here are some notes on integrating RPI with RPDM. This integration is required for several RPDM-dependent features in RPI such as:

  • Data Projects (Data Intake): supports importing flat files into RPI warehouse

  • Data Process Projects: supports running Data Management projects during the execution of an interaction workflow and/or interaction audience to augment RPI capabilities (e.g., couponing)

  • Channel States Import: leverages RPDM to facilitate import of channel execution fulfillment states results, most used in environments where high volume of results are generated

Calling RPDM from RPI requires RPDM Operational API (OAPI). The OAPI Download Center can be found here (direct links to the software download and the installation guide).

To configure RPI to run RPDM jobs using the DM Operational API web service configure the following settings in RPI:

  • DataManagementcredentials: set the credentials for connecting to RPDM

  • DataManagementExecutionServer: leave this value blank

  • Change DataManagementIntegrationType from 0 to 1

  • Configure parameter DataManagementOAPIWebServiceAddress to point to the base URL for the OAPI web service

  • DataManagementServerName: set to the RPDM site server hostname

  • DataManagementServerName: set to the site server port (normally 40420 for RPDM v9)

Example configuration:

Appendix D: Create the view for coupon resend

This is the statement to create the view for the coupon resend:

SQL
/******
Object:  View [dbo].[RPI_COUPON_ASSIGNMENT_RESEND]
Notes:   By having an inner join to Offer History this will
         ensure that any Coupon assignments that have been
         Rolled back will not be eligible for resend
******/

SET ANSI_NULLS ON;
GO

SET QUOTED_IDENTIFIER ON;
GO

CREATE VIEW [dbo].[RPI_COUPON_ASSIGNMENT_RESEND] AS
SELECT
    CA.[coupon_assignment_id],
    CA.[promotion_code],
    CA.[coupon_code],
    CA.[coupon_type],
    CA.[RPIResolutionKey],
    CA.[resolution_key_int01],
    CA.[resolution_key_int02],
    CA.[resolution_key_int03],
    CA.[resolution_key_str01],
    CA.[resolution_key_str02],
    CA.[resolution_key_str03],
    CA.[insert_ts],
    CA.[dataflow_id],
    CA.[workflow_id],
    CA.[output_id],
    P.[FirstName],
    P.[LastName],
    P.[PID],
    P.[EmailAddress],
    OH.OfferActivityName
FROM
    [RPIQASampleTenant].[dbo].[RPI_COUPON_ASSIGNMENT] CA
INNER JOIN
    Person P ON P.PID = CA.[resolution_key_int01]
INNER JOIN
    [dbo].[OfferHistory] OH ON CA.[resolution_key_int01] = OH.[PID]
    AND CA.[dataflow_id] = OH.[DataflowID]
    AND CA.[workflow_id] = OH.[WorkflowID];

GO

Appendix E: RPDM error

Data process project errors occur. This error is an indication that something is misconfigured in the RPDM project. In this case, the ProspectiveBuyerKey was spelled incorrectly in the RPDM job, so it was not able to select the field from the Dataflow table, and this is the error that it threw.


Appendix F: RPDM repositories for supporting coupons

In this appendix, the various RPDM repositories for supporting coupons will be saved.

RPDM coupon repository SQL

RPDM_CouponAssignmentArchive_SQL_V2.dlb
